Featuring a full carbon construction with an integrated 45 degree crown race. In addition, a triple cage mount features on both sides of this fork specifically for bikepacking front bags as well as inserts for fender mounts. This fork is ideally suited to the DEL RAY 3D. Supplied in standard satin black finish.
Technical Specification
Maximum tyre/wheel size: Up to 700x57mm / 27.5x2.6" depending on tyre/rim manufacturer
Material: Full carbon fibre UD finish
Fork steerer: 1" 1/8 to 1" 1/2 with D-shape and integrated 45 degree crown race
Steerer length: 350mm
Axle crown length: 395mm
Rake: 50mm
Crown diameter: 56mm
Disc brake rotor compatibility: Flat mount 160mm or 180mm
Max fork load: 15kg per side (5kg per eyelet)
Minimum tyre clearance at fork blade: 10mm (29"x2.25"), 8mm (27.5"x2.6")
